Installation Methods

Unique installation method of Plibrico which produces high installation consistency and mechanical strength

Plibrico dedicates towards development of original installation method which improves installation consistency as well as enhancing strength of furnace wall.
Through the development, we are successful to make practical use of certain materials, which have been theoretically best quality but regarded to be hard to install.

Hyrate installation method (Gunning application method of plastic refractories)

Hyrate method is an installation method originally developped by Plibrico for Gunning installation of Hyrate (Gunnable plastic refractory)
It makes possible to install with several times higher speed when compared with Ramming method of conventional plastic refractory and allowing even complicated shape plastic refractory wall installation. for a certain furnace wall, where plastic refractory is suitable but because of installation condition, castable refractory has been applied, by this development, plastic refractory has become available and made the furnace wall service life much longer than ever.

application example

■For continuous reheating furnace.

For continuous reheating furnace. For continuous reheating furnace.

■For municipal refuse incinerator

For municipal refuse incinerator For municipal refuse incinerator

other industrial equipments

■Cement plant (preheater, clinker cooler) ■Ignition furnace ■Industrial furnaces

PET installation method (wet gunning installation method of castable refractories)

PET method is wet gunning installation method which AGC Plibrico is proud of, and is most frequently adopted now.
Compared with dry gunning, a higher density strong wall can be constructed with PET, which makes it to be used for various equipments.
PET installation method is a gunning installation method which carries completely mixed wet castable material (Petgun) with gunning machine through compressed air pressure and mix it with quick setting agent being fed with compressed air just before gunning nozzle.
When the material is blew off from nozzle on to wall, with the coagulation action of quick setting agent, it instantly sets to build furnace wall.

[Example 1 of application] Square-sleeve duct ceiling part

[Example 1 of application] Square-sleeve duct ceiling part [Example 1 of application] Square-sleeve duct ceiling part [Example 1 of application] Square-sleeve duct ceiling part

[Example 2 of application] Clinker cooler side wall

[Example 2 of application] Clinker cooler side wall [Example 2 of application] Clinker cooler side wall [Example 2 of application] Clinker cooler side wall

Introduction of other installation methods

Gunning installation method
Ramming installation method
