Product Information

PマークProducts

Product Lines (from Plastic Refractories to Thin Lining Anchors) Workable in Various Applications and Installation Methods.

PLASTIC REFRACTORIES CASTABLE REFRACTORIES PRECAST BLOCKS TACKO ANCHOR
PLASTIC REFRACTORIES CASTABLE REFRACTORIES PRECAST BLOCKS TACKO®ANCHOR

Applications and installation condition are different in each case, and different installation method must be employed to best fit to each case. Plibrico responds to such diversified needs with a wide range of product lineup and installation method.

Pマーク CataLogue Dawnload

Company Profiel & Product Catalogue
(3.2013)
pdf
(4.92MB)
Get ADOBE READER A downloadable catalog is PDF form.
In order to take a look, Acrobat Reader of Adobe is required.

What are monolithic refractories ?

PマークPLASTIC REFRACTORIES

PLASTIC REFRACTORIES

Plastic refractories are clay-like products composed of refractory aggregates and fireclay powder, with addition of water and binder. Gunnable plastic refractories named HyRATE are also available.

What are monolithic refractories ?
Products Features Installation
Gunnable Plastic Refractories
PLIBRICO HyRATE
Innovative plastic refractories that can be applied simply by gunning without mixing with water at site.
Dense, light weight insulation and phosphate bond types are available.
Gunning
Rumming Refractories
PLITAB
PLIRAM
PLIBRICO SUPER
Refractories with plasticity for ramming installations. Ramming
Patching Refractories
PLITAB
PLIRAM
Putty-like refractories softer than rumming refractories. Recommendable for partial repair of small damaged areas. Patching
High Abrasion Resistance Plastic Refractory
PLIRAM CYCLONE MIX
Chemical-bonded refractory materials developed for applying to the linings of cyclone, transfer pipe, etc. of the FCC unit, which require high abrasion resistance. Ramming or
Hand Packing
Plastic Refractories
for Aluminum Melting Furnace
PLIRAM AL-TUFF
PLIBRICO HyRATE AL-TUFF
Plastic refractories for aluminum melting furnace and holding furnace, excellent in heat resistance and aluminum penetration resistance. Ramming
Gunning

Pagetop▲

PマークCASTABLE REFRACTORIES

CASTABLE REFRACTORIES

Castable refractories are powder-type products composed of refractory aggregates and refractory cement or special binder. Water is added when used at site. We offer a broad range of products and installation methods to meet the different applications of our customers including pouring, vibrating, troweling, dry gunning, wet gunning, and so on.

What are monolithic refractories ?
Products Features Installation
Wet Gunning Castable Refractories
PETGUN
PETGUN SIC
Castable refractories for PET (wet gunning method). Generates almost no dust compared to dry gunning and therefore provides clean work environment and excellent adhesion to the furnace shell and linings. Wet Gunning
(PET System)
Castable Refractories
PLICAST
Powder-type dry refractory materials composed of refractory aggregates and alumina cement or other powdered binder. Pouring
Vibrating
Troweling
High-Strength Castable Refractories
PLICAST SUPER HyMOR
High-strength castable refractories for vibration installation, possible to construct high-density and low-porosity lining. Vibrating
Free-flow Castable Refractories
PLIFLOW
Free-flow castable refractories, which develop good consistency with lower water ratio than ordinary castables. Excelled in strength. It is suitable for areas requiring high abrasion resistance. Pouring
Silicon Carbide Castable Refractories
PLICAST SIC
PLIFLOW SIC
High-strength castable refractories containing silicon carbide. Equipped with high strength and thermal conductivity and superior spalling resistance . Vibrating
Pouring
Acid Resistant Castable Refractories
PLICAST AR
Castable refractory good for use in linings of flue gas duct, stack and pressur vessel that require acid resistance. Pouring
Troweling
Castable Refractories
for Aluminum Melting Furnace
PLICAST AL-TUFF
Castable refractories for aluminum melting furnace and holding furnace, excelled in heat resistance and aluminum penetration resistance. Vibrating
Pouring
Insulating Castable Refractories
PLICAST LWI
PLICAST LITE
Light weight insulating castable refractories with low thermal conductivity and excellent insulation property. Pouring
Troweling
Gunning Castable Refractories
PLIGUN
Castable refractories developed for dry gunning installation. Gunning
Silicon Carbide Gunning Castable Refractories
PLIGUN SIC
Gunning castables including silicon carbide, equipped with high thermal conductivity. Excellent in gunning workability. Gunning
Acid Resistant Gunning Castable Refractories
PLIGUN AR
PLIGUN LAR
Gunning castable refractories good for use in linings of flue gas duct, stack and pressure vessel with acidic environment that require acid resistance. Gunning
Gunning Insulating Castable Refractories
PLIGUN LWI
Light weight insulating castables for gunning application, with low thermal conductivity and excellent insulation property. Gunning
Injection Refractories
PLISTIX BF MIX
Refractories for injection repair of local hot spots in oil refinery and petrochemical plant furnaces and steelmill blast furnaces. Applicable to hot condition repair. Injection
Coating Castable Refractories
PLICOAT
PLISTIX MIX
Coating refractories for repair of abraded surfaces of brick and castable linings. Troweling

PマークREFRACTORY MORTAR

Products Features Installation
Refractory Mortar
DEMON AIR SET
Powdery air-setting mortar for firebrick joints. Mixed with water when used at site. Sets hard after air drying and demonstrates high bonding strength at elevated temperatures. Troweling

PマークINSULATING PRODUCTS

Products Features Installation
Insulating Products
PLISULATE
Insulating materials used for insulation linings and back up linings of various types of furnaces. Available in various forms including powder, paste, board, felt, blanket, fiber and pipe shape.
Gunning Insulating Products
PLISULATE FG
Gunning insulation materials used for back up linings of complicated shape. Gunning

Pagetop▲

PマークPRECAST BLOCKS

PRECAST BLOCKS

With the advantages of monolithic refractories, AGC Plibrico provides pre-cast blocks of any shapes and types that meet the specific requirements of the customers. Use of pre-cast blocks enables easy installation at the job site to build up high-precision furnace linings.

PマークTACKO®ANCHOR

TACKO®ANCHOR

TACKO anchor is an innovative anchoring system for thin abrasion-resistant linings, developed by AGC Plibrico. Linings can be securely fixed without the disadvantages of the hexmesh support. Successfully used abrasion-resistant linings of various vessels including oil-refining equipments. We also provide a TACKO dual-lining system by combining with stud bolts.

details here

*(C) 2003 HyRATE(R),PLIBRICO(R), AL-TUFF(R), PETGUN(R) ,PET(R) , PLICAST(R) , PLIFLOW(R) , PLIGUN(R) , PLISTIX(R) , PLISULATE(R) , DEMON(R) , TACKO(R) are the registered trademark of AGC Plibrico Co.,Ltd.
